STH 42 ROTADAIRON

Stone buriers for Skid-Steer (mini- loader)

This soil and stone burier is designed for Skid-Steer (mini-loader). There are two versions of the machine hitch :

  • Toro / Ditch Witch / Vermeer type hitch plate: STH 42
  • Bobcat type hitch plate : STH 42 B
  • Adaptable to your carrier by your own : supplied without hitch plate, without hoses, without couplers: STH 42 ADAPT

It allows the building or renovation of green spaces by preparing the seed bed before seeding. The machine is multi-purpose, it allows tilling, burying (stones, rubbish, herbs, etc.), levelling, mixing and rolling the surface. The use is done live or on a ground previously decompacted in depth and cleared of large stones.

  • Oversized rotor
  • Anti-pad blades (Rotadairon® patent)
  • Selection grid fingers
  • Conventional quick hook system
  • Grader blade

Options

  • Fast coupling / uncoupling device
  • Rear mesh roller side adjustment device by cylinder
  • TurfRenov® Kit
  • Kit control TurfRenov®
  • Gravity Grass Seeder : SG 100
  • Spiral roller

Additional information

Weight 275 kg
STH 42 : HITCH PLATE

Toro / Ditch Witch / Vermeer

STH 42 B : Hitch plate

Bobcat

STH 42 ADAPT : HITCH PLATE

Without hitch plate, without hoses, without couplers

Working width

1100 mm (43'' 1/4)

Total width

1440 mm (56" 3/4)

Weight

STH 42 : 285 Kg (628.3 lb), STH 42 ADAPT : 275 Kg (606.2 lb), STH 42 B : 305 Kg (672.4 lb)

Carrier: Hydraulic flow

40 to 55 l/min (10.5 to 14.5 us gpm)

Carrier: Pressure

200 to 250 Bars (2900 to 3625 psi)

Max track width

STH 42 : 1.30 meters (51"1/4), STH 42 ADAPT : /, STH 42 B : 1.15 meters (45"1/4)

Working depth (max)

140 mm (5’’ 1/2)

Rotor outer diameter

400 mm (15’’ 3/4)

Depth adjustment

Rear roller height adjustable 4 positions

Number of blades

24

Grid finger spacing

22 mm (7/8'')

Forward speed of the carrier

0,8 to 1,5 Km/h (0.5 to 0.9 mph)

Rotor transmission

Security

Made by the carrier

Transport dimension (mm)

Rotadairon® STH 42 Tiller Stone buriers for Skid Steer

Description

Want to breathe new life into your field? Select one of our soil preparers, the Rotadairon® STH 42. This stone burier has a hitch that allows it to adapt to Skid Steer.

This stone burier is used in two ways. Either directly on your old ground, or on your unpacked ground and cleared of its large stones. This machine has a total width of 1440 mm (56″ ¾) and a working width of 1100 mm (43″ ¼). Thanks to its strength and power, it prepares your soil and buries detritus, grass and even rocks present on your surface. Its adjustable rear roller helps you control the working depth, which can go up to 140 mm (5” ½).

Its oversized rotor equipped with 24 patented anti-sole blades turns the ground upside down, thus burying the bulky waste from the old surface. The grid fingers retain the waste and the rocks leaving only the finest soil, which will then be levelled thanks to its height adjustable blade. Finally, its metal mesh roller allows a perfect finish of the terrain.

Our soil preparers replace many tools. In a single pass, your ground is clean, turned and oxygenated. With our Rotadairon® STH 42 Stone burier, your plot is ready for planting again.

Technical Specifications

Size of the machine

  • Width: 1440 mm (56″ ¾)
  • Length: 1545 mm (60″ ¾)
  • Height: 620 mm (24″ ½)
  • Total weight: 285 Kg (606.2 lb)

Work Dimension

  • Width: 1100 mm (43″ ¼)
  • Working depth: 140 mm (5” ½)

Equipment

  • Oversized rotor
  • Anti-pad blades (Rotadairon® patent)
  • Selection grid fingers
  • Conventional quick hook system
  • Soil preparation principle
  • Adjustable rear roller height
  • Grader blade

Option and additional accessory

  • Fast coupling / uncoupling device
  • Rear mesh roller side adjustment device by cylinder
  • TurfRenov® Kit
  • Kit control TurfRenov®
  • Gravity Grass Seeder
  • Spiral roller

Suggestions

The Rotadairon® STH 42 Stone buriers are to be used:

  • On deep unpacked ground
  • Directly on the parcel

Service and Warranty

The Rotadairon® STH 42 Stone buriers are delivered with:

  • A user manual
  • A one-year warranty certificate

It is possible to add a one-year warranty extension (additional option).

Download the product sheet

/
